Radio frequency characteristics

Number of interfaces:

2

Interface type:

7/8" EIA (50 Ω) conforming to IEC 60339-2.

7-16 plug (50 Ω) conforming to IEC 61169-4.

Interface direction:

right

Fixing:

no

Frequency range:

DC to 6 GHz

SWR, max:

1.02 @ DC at 2 GHz

1.06 @ 2 GHz to 4 GHz

1.11 @ 4 GHz to 6 GHz

Mechanical characteristics

Material / inner conductor cladding:

copper alloy / silver plated

Line conductor material / cladding :

copper alloy / silver plated

Insulation material:

PTFE

Weight, approx:

240,0 g

Length:

58.2 mm

Further remarks

Note:

- excellent electrical performance

(e.g. VSWR ≤ 1.02 / return loss ≥ 40 dB up to

1 GHz - exeption: 6 1/8" adaptor up to 800 MHz)

- for outdoor application

- also short length adapters available

Tariff item:

85366990
