Antena dipolo de FM polarización vertical AKF/1N

$416,500
Qty
Out-of-Stock

Broadband dipole FM antenna, available in three versions: aluminum, stainless steel or galvanized steel.

The AKS / 1 model is completely removable.

Wide band dipole, hot dipped steel, PTFE insulator and stainless steel screw, robust and resistant. Used in any climatic condition, all the metal parts are electrically grounded. You can find it in more versions: AKG/1N (connector "N") 800W, AKG/1M (connector "7/16") 2KW, AKG/1F (connector "7/8") 3 KW.

Specifications:

  • Freq. range: 87.5 - 108 MHz
  • Impedance: 50 Ohm
  • V.S.W.R. : <1.25:1
  • Gain: 2db
  • Connectors: 7/16"
  • Weight: 6,80 Kg
  • Max power: 2000 watt
  • Polarization: vertical
  • Dimensions: 1400x800x60 mm
  • Material: Stainless steel
